| Section | Specification | Unit | VL-200C | VL-200CM |
| CAPACITY | Max. Swing Diameter | mm | Ø2,500 | |
| Max. Turning Diameter | mm | Ø2,500 | ||
| Distance Between Ram and Table | mm | 825 - 1,825 | 860 - 1,860 | |
| Max. Turning Height | mm | 1,600 | ||
| Max. Workpiece Weight | kg | 12,000 | ||
| SPINDLE | Table Diameter | mm | Ø2,000 | |
| Spindle Speed | rpm | 5 - 200 | ||
| Gearbox (Stage) | 2 | |||
| Live Tool Speed | rpm | - | 50 - 2250 | |
| ATC | Tool Positions | Pcs | 12 | 16 |
| OD Tool Holder | mm | □ 25 , □ 32 , □ 40 | ||
| Ram Cross Section | mm | 250 x 250 | ||
| AXES | Rapid Feed (X, Z Axis) | m/min | 10 | |
| X Axis Travel | mm | -300 +1,450 | ||
| Z Axis Travel | mm | 1,200 | ||
| Cutting Feed | mm/rev | 0.001 - 500 | ||
| Cross Feeds | % | 0 - 150 | ||
| Cross Travel Distance | mm | 1,000 (250 x 4 Stages) | ||
| MOTOR | Spindle Motor (50% ED) | kw | AC 60 / 75 | |
| X, Z Axis Motor Power | kw | 5.5 / 5.5 | ||
| Live Motor Power | kw | - | AC 11 / 15 | |
| MACHINE SIZE | Width x Length | mm | 7,600 x 5,500 | |
| Height | mm | 6,650 | 7,000 | |
| Machine Weight | kg | 47,000 | 49,000 | |
