| MODEL | UNITS | UDM-4228 | |
| TABLE | Table Size | mm | 4000x2500 |
| T-Slots | mm | 22 | |
| Max. Workpiece Weight | ton | 16 | |
| AXES | X Axis | mm | 4200 |
| Y Axis | mm | 3200 | |
| Z Axis | mm | 800 (1000, 1200) | |
| SPINDLE | Spindle Servo Motor - cont./30min | kW | 15/18.5 (22/26) |
| Spindle Speed | rpm | 4000 (6000) | |
| Taper | - | 7/24 taper NO.50, BT-50 | |
| DISTANCE | Distance Between Columns | mm | 2800 |
| Spindle Nose to Table Distance | mm | 200~1000 (200~1200, 200~1400) | |
| RAPID FEED | X/Y/Z Rapid Feed | m/min | 12 / 12 / 10 |
| Minimum Setting | mm/min | 0.001 | |
| Cutting Speed | m/min | 1~5000 | |
| ATC | Tool Capacity | pcs | (24/32/40/60) |
| Tool Change Time | sec | 8 (Arm Type) | |
| Max. Tool Diameter / Length | mm | Ø125 / Ø200 (Without Adjacent Tool) / Length 350 | |
| Max. Tool Weight | kg | 18 | |
| COOLING & LUBRICATION | Coolant Tank Capacity | L | 700 |
| Hydraulic Tank Capacity | L | 80 | |
| Lubrication Tank Capacity | L | 8 | |
| OTHERS | Total Power | kVA | 50 |
| Air Pressure | kg/cm² | 7 | |
| Total Hydraulic Pressure | kg/cm² | 70 | |
| Machine Weight | ton | 48 | |
| Control Unit | - | FANUC 0iMF (FANUC 32i-B / 31i-B / MELDAS M70/720/730) (SIEMENS / HEIDE) | |
