| MODEL | UNIT | UDM-3215 | |
| TABLE | Table Size | mm | 3000x1300 |
| T-Slots | mm | 22 | |
| Max Workpiece Weight | kg | 5000 | |
| AXES | X Axis | mm | 3200 |
| Y Axis | mm | 1500 | |
| Z Axis | mm | 760 | |
| SPINDLE | Spindle Servo Motor (cont./30min) | kW | 11/15 (22/26) |
| Spindle Speed | rpm | 6000 | |
| Taper | - | 7/24 taper NO.50, BT-50 | |
| DISTANCE | Distance Between Columns | mm | 1500 |
| Spindle Nose to Table Distance | mm | 200~960 | |
| FEEDRATE | X/Y/Z Rapid Feedrate | m/min | 20/20/15 |
| Minimum Setting | mm/min | 0.001 | |
| Cutting Feedrate | m/min | 8 | |
| ATC | Tool Capacity | pcs | (24/32/40) |
| Tool Change Time | sec | 8 (ARM TYPE) | |
| Max Tool Diameter / Length | mm | Ø125 / Ø200 (Without Adjacent Tool) / Length 350 | |
| Max Tool Weight | kg | 15 | |
| COOLING & LUBRICATION | Coolant Tank Capacity | L | 240 |
| Hydraulic Tank Capacity | L | 70 | |
| Lubrication Tank Capacity | L | 8 | |
| OTHERS | Total Power | kVA | 40 |
| Air Pressure | kg/cm² | 5~8 | |
| Total Hydraulic Pressure | kg/cm² | 70 | |
| Machine Weight | kg | 21500 | |
| Control Unit | - | FANUC 0iMF (32i-B/31i-B), MELDAS M70/720/730, SIEMENS, HEIDENHAIN | |
