| Section | Specification | Unit | VP-10 |
|---|---|---|---|
| TABLE | Table Size | mm | 1070 x 510 |
| Max Load Weight | kg | 500 | |
| Table Height | mm | 900 | |
| T-Slots | mm | 18 x 5 | |
| Spindle Nose to Table Distance | mm | 100 - 700 | |
| SPINDLE | Spindle Taper | - | BT40 |
| Spindle Speed | rpm | 10,000 (15,000) | |
| AXES | X Axis Travel | mm | 1020 |
| Y Axis Travel | mm | 510 | |
| Z Axis Travel | mm | 600 | |
| Rapid Feed Rate | m/min | 36 / 36 / 36 | |
| Cutting Feed Rate | mm/min | 1 - 10,000 | |
| ATC | Tool Capacity | pcs | 24 |
| Max Tool Diameter | mm | Ø75 / Ø150 | |
| Max Tool Length | mm | 300 | |
| Max Tool Weight | kg | 7 | |
| MOTOR | Spindle Motor Power (50% ED) | kW | 15 |
| Servo Motor X/Y/Z | kW | 2.2 / 2.2 / 3.0 | |
| Cooling Motor | kW | 0.37 | |
| MACHINE SIZE | Width x Length | mm | 2280 x 2642 |
| Height | mm | 3010 | |
| Net Weight | kg | 5200 |
