| Section | Specification | Unit | EZ-7 |
|---|---|---|---|
| TABLE | Table Size | mm | 850 X 410 |
| Max Load Capacity | kg | 250 | |
| Table Height | mm | 850 | |
| T-Slots | mm | 18 X 3 | |
| Distance from Spindle Nose to Table | mm | 200 - 500 | |
| SPINDLE | Spindle Taper | BBT30 | |
| Spindle Speed | rpm | 12,000 (20,000 / 24,000) | |
| AXES | X Axis Travel | mm | 710 |
| Y Axis Travel | mm | 400 | |
| Z Axis Travel | mm | 300 | |
| Rapid Traverse Rates | m/min | 60 / 60 / 60 | |
| Cutting Feed Rate | mm/min | 1 - 20,000 | |
| ATC | Tool Capacity | pcs | 16 (21) |
| Max Tool Diameter | mm | Ø80 | |
| Max Tool Length | mm | 200 | |
| Max Tool Weight | kg | 3 | |
| MOTOR | Spindle Motor Power (50% ED) | kW | 3.7 / 5.5 |
| Servo Motor X/Y/Z | kW | 1.5 / 2.2 / 2.2 | |
| Cooling Motor | kW | 0.18 | |
| MACHINE SIZE | Width X Length | mm | 2,100 X 2,600 |
| Height | mm | 2,700 | |
| Net Weight | kg | 2,850 |
