Our goal is to provide manufacturers with the most suitable solutions while acting in an environmentally conscious manner, valuing human labor, and growing sustainably in strong harmony with our business partners. Thanks to the long-term and trust-based collaborations we have established with our suppliers, we aim to add value both to our country and to our company.
| Section | Specification | Unit | LWT 3080 |
| BASIC TECHNICAL SPECIFICATIONS | Max. Workpiece Diameter | mm | Ø300 |
| Min. Workpiece Diameter | mm | 5 | |
| Max. Module | 12 | ||
| Min. / Max. Number of Teeth | 1 / 99 | ||
| Max. Slot Angle | degree | ±35 | |
| Max. Cutting Angle | degree | 5° / 30° | |
| Min. / Max. Center Distance | mm | 80 ~ 800 | |
| Max. Grinding Axial Travel Distance | mm | 430 | |
| Max. Workpiece Weight | kg | 60 | |
| Distance Between Workpiece Axis and Grinding Axis (Min. / Max.) | mm | 145 / 345 | |
| TOOL INFORMATION | Min. / Max. Wheel Diameter | mm | 280 / 400 |
| Max. Wheel Speed | rpm | 6,000 | |
| Max. Wheel Width | mm | 40 | |
| Wheel Motor Power | kW | 17 | |
| ELECTRICAL SYSTEM | Voltage | V | 220 |
| Current Requirement | Amp | 50 | |
| Operating Room Temperature Requirement | °C | 10 ~ 40 | |
| Total Power | kVA | 20 | |
| CNC | Control Unit | Fanuc | |
| WEIGHT AND DIMENSIONS | Machine Dimensions (W x L x H) | mm | 3,836 x 4,074 x 2,443 |
| Machine Weight | kg | 8,000 |
