| Section | Specification | Unit | LWT 2080 |
| BASIC TECHNICAL SPECIFICATIONS | Max. Workpiece Diameter | mm | Ø200 |
| Min. Workpiece Diameter | mm | 5 | |
| Max. Module | 8 | ||
| Min. / Max. Number of Teeth | 1 / 99 | ||
| Max. Slot Angle | degree | ±30 | |
| Max. Cutting Angle | degree | 5° / 30° | |
| Min. / Max. Center Distance | mm | 80 ~ 800 | |
| Max. Grinding Axial Shift Distance | mm | 430 | |
| Max. Workpiece Weight | kg | 40 | |
| Distance Between Workpiece Axis and Grinding Axis (Min. / Max.) | mm | 145 / 345 | |
| TOOL INFORMATION | Min. / Max. Wheel Diameter | mm | 280 / 400 |
| Max. Wheel Speed | rpm | 6.000 | |
| Max. Wheel Width | mm | 40 | |
| Wheel Motor Power | kW | 17 | |
| ELECTRICAL SYSTEM | Voltage | V | 220 |
| Current Requirement | Amp | 50 | |
| Operating Room Temperature Requirement | °C | 10 ~ 40 | |
| Total Power | kVA | 20 | |
| CNC | Control Unit | Fanuc | |
| WEIGHT AND DIMENSIONS | Machine Dimensions (Width x Length x Height) | mm | 3.836 x 4.074 x 2.443 |
| Machine Weight | kg | 7.000 |
