| Section | Specification | Unit | SH-4500P |
| TABLE | Table Size | mm | 400 x 400 (Opt. 500 x 500) |
| Max. Load Capacity | kg | 450 | |
| Table Height | mm | 1,200 | |
| Workpiece Size | mm | Ø630 x 900 | |
| B-Axis Angle | degree | 0.001º | |
| SPINDLE | Spindle Taper | 7/24 Taper No.40 | |
| Spindle Speed | rpm | 15,000 | |
| AXES | X-Axis Travel | mm | 630 |
| Y-Axis Travel | mm | 630 | |
| Z-Axis Travel | mm | 730 | |
| Distance from Spindle Center to Table | mm | 80 - 710 | |
| Distance from Spindle Nose to Table | mm | 70 - 800 | |
| X/Y/Z Rapid Traverse Rates | m/min | 60 / 60 / 60 | |
| Cutting Feed Rate | mm/rev. | 1 - 20,000 | |
| ATC | Tool Capacity | 40 (Opt. 60) | |
| Tool Holder | BT-40 (BBT-40) | ||
| Max. Tool Diameter | Ø75 | ||
| Max. Tool Length | mm | 450 | |
| Max. Tool Weight | kg | 8 | |
| MOTOR | Spindle Motor Power (50% ED) | kw | 37 / 26 / 18.5 |
| X/Y/Z Servo Motor | kw | 5.5 / 5.5 / 4.5 | |
| Coolant Motor | kw | 1.5 x 5 | |
| GENERAL MACHINE | Width x Length | mm | 2,200 x 5,700 |
| Height | mm | 2,985 | |
| Net Weight | kg | 11,800 |
