| Section | Specification | Unit | MT-1500 | MT-1500M |
|---|---|---|---|---|
| TURNING CAPACITY | Max. Swing Diameter | mm | Ø210 | |
| Max. Turning Diameter Over Carriage | mm | Ø230 | ||
| Max. Turning Diameter | mm | Ø210 (Ø120 with Robot) | ||
| Max. Turning Length | mm | 145 (100 with Robot) | ||
| SPINDLE | Spindle Taper | A2-5 | ||
| Spindle Speed | rpm | 4,500 | ||
| Chuck Diameter | inch | 6″ | ||
| Spindle Bore | mm | Ø56 | ||
| Bar Capacity | mm | Ø65 | ||
| Spindle Bearing Diameter | mm | Ø80 | ||
| Spindle Center Height from Floor | mm | 1,300 | ||
| TURRET | Tool Capacity | pcs | A2-6 | – |
| External / Internal Tool Size | mm | 25 x 25 / Ø32 | – | |
| POWER TURRET | Tool Capacity | pcs | – | 12 |
| External / Internal Tool Size | mm | – | 25 x 25 / Ø32 | |
| Max. Speed | rpm | – | 5,000 | |
| Motor | kW | – | 5.5 | |
| AXES | X / Z Travel | mm | 155 / 155 | |
| X / Z Rapid Traverse | m/min | 30 / 30 | ||
| Cutting Feedrate | mm/min | 0.001 – 5,000 | ||
| MOTOR | Spindle Motor (50% ED) | kW | 11 | |
| X / Z Servo Motor | kW | 1.8 / 1.8 | ||
| Coolant Motor | kW | 0.55 x 2 | ||
| MACHINE SIZE | Width x Depth | mm | 4,200 x 2,845 | |
| Height | mm | 3,120 | ||
| Machine Weight | kg | 5,500 | 5,700 | |
