| Section | Specification | Unit | VH-85 |
| TABLE | Table Size | mm | 1000 X 520 |
| Max. Load Capacity | kg | 600 | |
| T-Slots | mm | 18 X 5 X 100 | |
| Distance Spindle Nose to Table | mm | 110-660 | |
| SPINDLE | Spindle Taper | BT40 | |
| Spindle Speed | rpm | 10000 / 12000 | |
| AXES | X Axis Travel | mm | 850 |
| Y Axis Travel | mm | 550 | |
| Z Axis Travel | mm | 550 | |
| Rapid Feed Rates | m/min | 36 / 36 / 36 | |
| Cutting Feed | mm/min | 1-10,000 | |
| ATC | Tool Capacity | pcs | 24 |
| Max. Tool Diameter | mm | Ø80 / Ø150 | |
| Max. Tool Length | mm | 300 | |
| Max. Tool Weight | kg | 8 | |
| MOTOR | Spindle Motor Power (50% ED) | kw | 11 / 18.5 |
| Servo Motor X/Y/Z | kw | 3.0 / 3.0 / 3.0 | |
| MACHINE DIMENSIONS | Width x Length | mm | 2,500 / 2,750 |
| Height | mm | 2,790 | |
| Net Weight | kg | 5,000 |
