| Section | Specification | Unit | V-8B |
| TABLE | Table Size | mm | 1000 X 500 |
| Max. Load Capacity | kg | 600 | |
| T-Slots | mm | 18 X 5 X 80 | |
| Distance Spindle Nose to Table | mm | 120-670 | |
| SPINDLE | Spindle Taper | BT40 | |
| Spindle Speed | rpm | 12,000 | |
| AXES | X Axis Travel | mm | 820 |
| Y Axis Travel | mm | 550 | |
| Z Axis Travel | mm | 550 | |
| Rapid Traverse Rates | m/min | 48 / 48 / 48 | |
| Cutting Feed Rate | mm/min | 1-10,000 | |
| ATC | Tool Capacity | pcs | 24 |
| Max. Tool Diameter | mm | Ø80 / Ø150 | |
| Max. Tool Length | mm | 300 | |
| Max. Tool Weight | kg | 8 | |
| MOTOR | Spindle Motor Power (50% ED) | kW | 7.5 / 15 |
| Servo Motor X/Y/Z | kW | 2.0 / 2.0 / 3.0 | |
| MACHINE SIZE | Width x Length | mm | 2,400 / 2,700 |
| Height | mm | 2,850 | |
| Net Weight | kg | 4,450 |
