| Section | Specification | Unit | V-13 |
| TABLE | Table Size | mm | 1400 X 700 |
| Maximum Load Weight | kg | 850 | |
| T-Slots | mm | 18 X 5 X 125 | |
| Distance from Spindle Nose to Table | mm | 130-830 | |
| SPINDLE | Spindle Taper | BT40 / BBT40 | |
| Spindle Speed | rpm | 8000 / 12000 | |
| AXES | X Axis Travel | mm | 1300 |
| Y Axis Travel | mm | 700 | |
| Z Axis Travel | mm | 700 | |
| Rapid Feed Rates | m/min | 24 / 24 / 24 | |
| Cutting Feed Rate | mm/min | 1-10,000 | |
| ATC | Tool Capacity | pcs | 24 |
| Maximum Tool Diameter | mm | Ø80 / Ø150 | |
| Maximum Tool Length | mm | 300 | |
| Maximum Tool Weight | kg | 8 | |
| MOTOR | Spindle Motor Power (50% ED) | kw | 11/18.5 |
| Servo Motor X/Y/Z | kw | 3.0 / 3.0 / 3.0 | |
| MACHINE SIZE | Width X Length | mm | 3,290 / 3,210 |
| Height | mm | 3,145 | |
| Net Weight | kg | 8,130 |
