| Section | Specification | Unit | JVH-630 |
| TABLE | Table Size | mm | 630 X 630 |
| Max. Workpiece Size | Ø1200x720 | ||
| Max. Load Capacity | kg | 1200 | |
| Distance from Spindle Nose to Table | mm | 70 - 880 | |
| SPINDLE | Spindle Taper | BT50 | |
| Spindle Speed | rpm | 4500 | |
| AXES | X Axis Travel | mm | 1300 |
| Y Axis Travel | mm | 950 | |
| Z Axis Travel | mm | 710 | |
| Rapid Traverse Rates | m/min | 20 / 20 / 20 | |
| Cutting Feed Rate | mm/min | 1-10,000 | |
| ATC | Tool Capacity | pcs | 30 |
| Max. Tool Diameter | mm | Ø125 / Ø200 | |
| Max. Tool Length | mm | 400 | |
| Max. Tool Weight | kg | 18 | |
| MOTOR | Spindle Motor Power (50% ED) | kw | 15 / 18.5 |
| Servo Motor X/Y/Z | kw | 3.0 / 3.0 / 3.0 | |
| MACHINE DIMENSIONS | Width X Depth | mm | 5,465 / 4,285 |
| Height | mm | 3,635 | |
| Net Weight | kg | 12,000 |
