| Section | Feature | Unit | LFG 8040 |
| BASIC TECHNICAL FEATURES | Max. Workpiece Diameter | mm | Ø800 |
| Min. Workpiece Diameter | mm | Ø50 | |
| Grinding Cutter Max. Profile Height | mm | 48 | |
| Max. Module | 20 | ||
| Helix Angle / Rotary Angle Grinding Wheel | mm | ±35° | |
| Max. Grinding Slide Travel ( Y Axis ) | 400 ( 450 ) | ||
| Max. Workpiece Slide Travel ( Z Axis ) | degree | 400 | |
| Distance Between Tailstock Center and Table | mm | 600 ~ 1.300 | |
| Table Diameter | mm | 740 | |
| Max. Table Load Capacity | kg | 2500 | |
| TOOL INFORMATION | Min. / Max. Wheel Diameter | mm | 280 / 400 |
| Max. Wheel Speed | rpm | 4.000 | |
| Max. Wheel Width | mm | 90 | |
| Wheel Motor Power | kW | 15 | |
| ELECTRICAL SYSTEM | Voltage | V | 220 |
| Current Requirement | Amp | 80 | |
| Operating Room Temperature Requirement | °C | 10 ~ 40 | |
| Total Power | kVA | 30 | |
| CNC | Control Unit | Fanuc | |
| WEIGHT AND DIMENSIONS | Machine Dimensions ( W x L x H ) | mm | 6.400 x 5.700 x 4.200 |
| Machine Weight | kg | 15.000 |
